型号:12G SDI LWDM&MWDM Video SFP+ Optical Transceiver(18 channels)
12G SDI LWDM&MWDM Video SFP+ Optical Transceiver(18 channels)
12G SDI LWDM&MWDM Video SFP+ Optical Transceiver(18 channels) 详情





Download List





12G SDI LWDM&MWDM Video SFP+ Optical Transceiver(18 channels)

Features:
Ø  SDI Multi-rate LWDM&MWDM Video SFP+ transceiver for 12G-SDI, 6G-SDI, 3G-SDI HD-SDI and SD-SDI
Ø  Support for SMPTE 2082, SMPTE 2081, SMPTE 424M, and SMPTE 292M
Ø  Support pathological pattern transmission
Ø  Single 3.3V power supply
Ø  Operating case temperature: 0 to +70°C
Ø  Operating data rate up to11.88Gbps
Ø  Transmission distance with 9/125μm SMF up to 10km at 11.88G
Ø  LWDM 12 channels & MWDM 6 channels
Ø  Pluggable and hot swappable
Ø  Lead free and RoHS compliant
Ø  Class I laser product
Ø  Compliant with SFP MSA
Ø  Compliant with SFF-8472
