型号:CSFP


Applications



Ø   Point-to-Point FTTX Application

Ø   100BASE-BX10/20

Ø   1000BASE-BX10/20

Ø   Other optical links

CSFP 详情

Download List



CSFP compact SFP Bi-directional optical transceivers



Features



Ø   Compliant with CSFP MSA 2.0 (Option 2)

Ø   Support data rate 125M,1.25G, Dual rate 125M/1.25G

Ø   Two Bi-Directional Transceivers in One SFP Package

Ø   Compliant with IEEE 802.3ah, 1000Base-BX10-U and 1000Base-BX10-D

Ø   Compliant with IEEE 802.3ah, 100Base-BX10-U and 100Base-BX10-D

Ø   Duplex LC Connector

Ø   Single 3.3V Supply

Ø   10.5dB Minimum Power Budget, 10km Minimum Reach for 1000Base-BX10-U/D

Ø   15dB Minimum Power Budget, 20km Minimum Reach for 1000Base-BX20-U/D

Ø   14dB Minimum Power Budget,10km Minimum Reach for 100Base-BX10-U/D

Ø   18dB Minimum Power Budget,20km Minimum Reach for 100Base-BX20-U/D

Ø   1310nm FP Laser, 1490nm PIN Receiver for 1000Base-BX10/20-U

Ø   1490nm DFB Laser, 1310nm PIN Receiver for 1000Base-BX10/20-D

Ø   1310nm FP Laser, 1550nm PIN Receiver for 100Base-BX10/20-U

Ø   1550nm FP Laser, 1310nm PIN Receiver for 100Base-BX10/20-D

Ø   Commercial and Industrial Temperatures Available

Ø   Compatible with SFF-8472 Rev 9.5

Ø   Compatible with FCC 47 CFR Part 15, Class B

Ø   Compatible with FDA 21 CFR 1040.10 and 1040.11, Class I

Ø   Compliant with RoHS
