型号:10G SDH/SONET SFP+


Application

Ø  SONET(OC-192)/SDH(STM64) Line Card

Ø  8.5Gb/s Fiber Channel

Ø  10.5Gb/s Fiber Channel

Ø  Computer Cluster Cross-Connect.

Ø  G.709 OTU1e/2/2e FEC bit rates



10G SDH/SONET SFP+ 详情

Download List



10G SDH/SONET SFP+ optical transceivers



Features



Ø   1310 DFB/1550nm EML transmitter and PIN/APD receiver

Ø   Support 8G FC, 10GBASE-LR/LW; ER/EW; ZR/ZW and SONET/SDH application

Ø   Support multi-rate 8.5G and 9.95G to 11.3G

Ø   Max link length up to 10km/40km/80km on SMF

Ø   Duplex LC connector

Ø   Dual CDR integrated for ER and ZR

Ø   Hot-pluggable with SFP+ form factor

Ø   RoHS Compliant and Lead-Free

Ø   Built-in digital diagnostic functions

Ø   SFI high speed interface

Ø   Single 3.3V power supply

Ø   power consumption: < 1.5W for LR /2W for ER and ZR

Ø   Operating temperature range:

Commercial -5°C to 70°; Industrial -40°C to 85°CI

Ø   Compatible with SFP+ MSA:SFF-8431 Rev 4.1

Ø   Compatible with 8G FC, 10GBASE-LR/LW and OC192 SONET/SDH

Ø   ESD to the Electrical PINs: compatible with MIL-STD-883E Method 3015.7

Ø   ESD to the Duplex LC Receptacle: compatible with IEC 61000-4-2 GR-1089-CORE

Ø   Immunity compatible with IEC 61000-4-3

Ø   EMI compatible with FCC Part 15 Class B EN55022 Class B (CISPR 22B) VCCI Class B

Ø   Laser Eye Safety compatible with FDA 21CFR 1040.10 and 1040.11 EN60950, EN (IEC) 60825-1,2

Ø   RoHS compliant with 2002/95/EC 4.1&4.2 2005/747/EC
