SGMII SFP optical transceivers

Features

Ø   Built-in PHY supporting SGMII Interface

Ø   Built-in high performance MCU supporting easier configuration

Ø   Support more link status monitor, such as CRC error counter, package counter and Far End Fault Indication (FEFI)

Ø   125M operation; 125M/1250M dual rate operation

Ø   1310nm FP/DFB laser and 1550nm DFB laser

Ø   PIN photo-detector

Ø   2km MMF transmission at 125M;500m MMF transmission at 1.25G

Ø   10km/40km/80km SMF transmission at 125M and 1.25G

Ø   Standard serial ID information compatible with SFP MSA

Ø   SFP MSA package with duplex LC connector

Ø   +3.3V single power supply

Ø   Operating case temperature

Commercial: 0 to +70°C; Industrial: -40 to +85°C

Ø   Compatible with SFP MSA

Ø   Compatible with IEEE 802.3-2002

Ø   Compatible with FCC 47 CFR Part 15, Class B

Ø   Compatible with FDA 21 CFR 1040.10 and 1040.11, Class I

Ø   Compatible with Telcordia GR-468-CORE

Ø   RoHS compliance
