4.25G Fiber Channel SFP optical transceivers

Features

Ø   Tri-rate 1.0625/2.125/4.25Gbps bi-directional data links

Ø   850nm VCSEL laser/1310nm DFB/1550nm DFB transmitter

Ø   PIN/APD photodetector

Ø   Duplex LC optical interface

Ø   Up to 150m on 50/125μm MMF at bit rate 4.25Gbps

Ø   Up to 70m on 62.5/125μm MMF at bit rate 4.25Gbps

Ø   Up to 10km/40km/80km SMF at bit rate 4.25Gbps

Ø   Monitoring interface compliant with SFF-8472

Ø   Low power dissipation

Ø   Class I laser product

Ø   Low EMI and excellent ESD protection

Ø   Single +3.3V power supply

Ø   Operating case temperature:

Standard: -5 to +70°C; Industrial: -40 to +85°C

Ø   Compatible with SFP MSA

Ø   Compatible with SFF-8472 Rev 9.5

Ø   Compliant with ANSI specifications for Fibre Channel

Ø   Compatible with FCC 47 CFR Part 15, Class B

Ø   Compatible with FDA 21 CFR 1040.10 and 1040.11, Class I

Ø   Compliant with RoHS
